AUX PREMIUM DUCTED 5KW

DUCTED UNITS

AUX-M-D(07/09/12/18/24)/I

• SLIM DESIGN - ONLY 200mm OF THICKNESS
  Thanks to the extremely flat design, the AUX duct units are perfect for rooms with limited installation space. The low height of the casing - only 200 mm - makes it possible to install the unit even in low ceiling spaces.
• IDDEN AIR CONDITIONING SYSTEM
  Duct units are designed to be built-in - they offer silent operation and wide range of installation modes. Once installed in the suspended ceiling, they are invisible, and the air is distributed through channels to the vents which can be designed flexibly

BUILD-IN CONDENSATE PUMP

Lifting height up to 70 cm

The AUX duct unit can be additionally equipped with a condensate pump, which allows to drain the water condensate up to 70 cm above the drain pan level.

TECHNICAL DATA

Model			AUX-M-D07/I	AUX-M-D09/I	AUX-M-D12/I	AUX-M-D18/I	AUX-M-D24/I
Cooling capacity		[kW]	2,20 (1,13 – 2,70)	2,60 (1,50 – 3,55)	3,52 (1,35 – 4,40)	5,28 (1,53 – 5,60)	7,03 (2,16 – 8,20)
		[Btu/h]	7506 (3855 – 9220)	8872 (5120 – 12115)	12000 (4600 – 15000)	18000 (5200 – 19100)	24000 (7400 – 28000)
Heating capacity		[kW]	2,50 (1,34 – 3,17)	2,90 (1,70 – 3,65)	3,81 (1,24 – 5,30)	5,60 (1,40 – 6,20)	7,91 (1,98 – 9,30)
		[Btu/h]	8530 (4575 – 10820)	9895 (5800 – 12450)	13000 (4200 – 18100)	19100 (4800 – 21200)	27000 (6800 – 31700)
Power supply		[V~,Hz,Ph]	220-240, 50, 1	220-240, 50, 1	220-240, 50, 1	220-240, 50, 1	220-240, 50, 1
Power consumption in cooling mode		[W]	55	55	60	90	150
Power consumption in heating mode		[W]	55	55	60	90	150
Fan motor power		[W]	40	40	50	73	120
Fan speed (high / medium / low)		[rpm]	1020/870/780	1020/870/780	980/880/800	1180/1050/930	1200/1065/960
Airflow (high / medium / low)		[m³/h]	600/450/380	600/450/380	720/600/500	900/750/630	1400/1190/980
Sound pressure level		[dB(A)]	37/33/30	37/33/30	36/34/32	41/37/34	42/39/36
Sound power level		[dB(A)]	53	53	49	56	55
ESP		[Pa]	10/30	10/30	25 (0 ~ 80)	25 (0 ~ 80)	25 (0 ~ 80)
Unit dimensions		[mm]	700 x 470 x 200	700 x 470 x 200	700 x 700 x 245	700 x 700 x 245	1000 x 700 x 245
Unit weight (net)		[kg]	18,5	18,5	21,0	22,0	29,5
Refrigerant		–	R32	R32	R32	R32	R32
Pipe connections (diameter)	Liquid	[mm/(inch)]	6,35 (1/4)	6,35 (1/4)	6,35 (1/4)	6,35 (1/4)	9,52 (3/8)
	Gas	[mm/(inch)]	9,52 (3/8)	9,52 (3/8)	12,70 (1/2)	12,70 (1/2)	15,88 (5/8)
	Condensate	[mm]	16,50	16,50	16,50	16,50	16,50
