Ecosun U-Series infrared panel 80 x 120 cm - 850 Watt

The Ecosun panel with granular texture can be easily mounted on the wall or on the ceiling. This panel is finished with a white textured paint, which ensures that the heat is evenly distributed throughout the entire room.

Thanks to the IP44 rating, this panel is also very safe and water-resistant, so you can, for example, use it in the bathroom. This panel is made entirely of aluminium and is therefore very lightweight.

Features of the Ecosun textured panel

- Fully insulated back
- Made of metal and coated in white RAL (9010)
- IP44 approved
- Thickness of just 30 mm
- Equipped with thermal protection; the panel never gets hotter than 90°C
- Can be easily mounted to the ceiling thanks to the supplied mounting bracket
- Technical support available from 09:00 to 17:00

The panel is supplied with

- Instruction manual
- 2-meter power cable
- Mounting bracket
- 5-year warranty

Required power

• 35 Watts per m³ for living rooms
• 30 Watts per m³ for bedrooms
• 60 Watts per m³ for bathrooms

Controlling the panel temperature

The Ecosun panels are delivered ready to use and include a connection cable. To control the temperature in your home, the infrared heater must be controlled by a thermostat. This will switch the electrical current on or off.
