Ecosun VT Series infrared panel 59x59 300 Watt

The Ecosun VT infrared panel with granol texture can be easily installed in your suspended ceiling. This panel is finished with a white textured paint, which ensures that the heat is evenly distributed throughout the entire room. The panel is equipped with a 15 mm drop profile.

Features of the Ecosun VT suspended ceiling panel with texture

- Fully insulated back
- Metal and coated in white RAL (9016)
- Dimensions: 59.2 x 59.2 x 3.5 cm
- 15 mm drop profile
- IP20 rated
- Thickness of only 30 mm
- Equipped with thermal protection so the panel never gets warmer than 90 °C
- Can easily be mounted on the wall or ceiling thanks to the supplied mounting bracket
- Technical support available from 09:00 to 17:00

The panel is supplied including

- Instruction manual
- 2-meter power cable
- Mounting bracket
- 5 year warranty

Required power

• 35 watts per m³ for living rooms
• 30 watts per m³ for bedrooms
• 60 watts per m³ for bathrooms

For more information about the required power

Controlling the panel temperature

The Ecosun panels are supplied without a power cord. To be able to control the temperature in your home, the infrared heating must be controlled by a thermostat. This will switch the electrical current on or off. Go to the thermostats.
