Second chance - QH-HL Series infrared panel with LED lighting 63 x 108 cm - 700 Watt - Default

Note: Second chance item The product itself is complete and functions as expected; all parts are present. The original box was damaged during transport, causing the packaging to look used; this has no effect on the operation of the product.

The Quality Heating HT panel with LED lighting can be easily mounted to the ceiling. This panel features a smooth white finish and an integrated adjustable LED lighting. A remote control thermostat is supplied with the panel as standard. This remote control thermostat can be easily mounted on the wall. With the remote control thermostat you can easily set the desired temperature and program. The LED lighting is dimmable in steps (25, 50, 75 or 100%) or smoothly (5-100%) and can be switched between 3 light colors: Cool white (6000K), Warm white (3000K) or combined for daylight (4500K). Of course you can also set the desired room temperature with this thermostat. If you want to use this panel in the bathroom, that is also possible. The panel has an IP52 rating, making it safe and splash-resistant.

Features of the Quality Heating HT panel with LED

- Fully insulated back
- Panel dimensions 630*1080*35 mm (thermostat housing) is wirelessly connected to the panel
- Metal and coated in RAL white (9016)
- IP52 approved
- Thickness of just 35 mm
- Equipped with thermal protection so the panel never gets hotter than 130 °C
- Can only be mounted to the ceiling with the supplied mounting screws
- Equipped with LED ambient lighting (warm white)
- Technical support available from 09:00 to 17:00

Number of lumens

108 x 63 cm, 3000 lumens

The panel is supplied with

- Instruction manual
- 1.8 m power cable
- Remote control 86*86*23 mm (without batteries)
- Mounting screws with plugs

Required power

• 35 Watt per m³ for living rooms
• 30 Watt per m³ for bedrooms
• 60 Watt per m³ for bathrooms

[files]

Documents

HH LED - Manual
