Simple Plug-in Thermostat

The plug-in thermostat with room temperature sensor is the simplest solution to get your infrared heat panel or conventional heating up and running immediately. Simply plug the thermostat into the power outlet and then connect the infrared panel or central heating to the thermostat. This Plug-In thermostat cannot be programmed.

With this model, simply set a temperature between 5 and 45 degrees Celsius. It is also ideal for frost protection. (temperature set to 5 degrees)

Applications

- All infrared heating panels
- Conventional heating and central heating

Technical data

- Connection voltage: 230Vac ("plug-in" model)
- Output voltage: 230Vac
- IP value: 20
- Switching capacity: 3600VA (16A) with ohmic load
- On/off switch: yes
- Temperature setting: 5 ~ 45°C, adjustable with pushbuttons
- Temperature measurement: ambient, via internal sensor
- Self-regulation / Optimization: no/no
- Frost protection: no
- Display indication: programmed temperature, measured temperature, heating
- Sensor monitoring: yes
- Dimensions: 125 x 70 x 39 mm, display 37 x 16 mm
- Color: white/white
- EEPROM: yes (memory in case of power outage)
- Certification: CE.
- Warranty: 2 years.
